Disjuntor em caixa moldada UL489 NDM3EU-225

2024年3月13日Produto de baixa tensão Produto de Energia Renovável UL489 MCCB19880

Certificações disponíveis UL A disponibilidade depende do modelo e da configuração.

Visão geral

The UL489 NDM3EU-225 is an electronic molded-case circuit breaker developed for North American low-voltage distribution systems. It combines overload long-delay, short-circuit short-delay and instantaneous protection in a compact frame.

Disjuntor em caixa moldada UL489 NDM3EU-225

Vantagens do produto

Electronic ProtectionAdjustable electronic functions coordinate overload and short-circuit protection.

UL ComplianceCertification supports use in North American distribution equipment and panels.

Flexible SettingsFrame ratings and trip settings can be matched to the protected feeder.

Practical IntegrationFixed, rear plug-in and lug-terminal arrangements support different panel designs.

Especificações típicas

Rated Insulation Voltage	800 V
Tensão nominal	AC 240 / 480 V
Frame Current	Up to 225 A
Interrupting Capacity	65 kA at AC 240 V; 35 kA at AC 480 V
Mechanical / Electrical Life	4,000 / 4,000 operations
Certifications	UL 489, UL 486E, UL 1998

Apenas configuração típica. As potências nominais finais são confirmadas de acordo com os requisitos do projeto.

Aplicações

Suitable for industrial switchboards, distribution panels and commercial power systems requiring electronic protection and UL-certified equipment.

ÚLTIMO: NDB6AZ-125H 5G DC miniature circuit breakerPRÓXIMO: Norma IEC 60947-2 UL 489 NDB2T-63 3P

Recomendações relacionadas

NDM3-100 4P
2023年5月26日 1770
Part No.:NDM3-100 4P ● Product Details Model Number: NDM3-100 4P Brand Name: Nader Origin: China (mainland) Small Orders: Accepted ● Use & Scope of ApplicationThisAircircuit&nb...
Ver detalhes
SVM5H-250H MCCB de 1000 V CA
2023年11月24日 1870
General SVM5H series of moulded case circuit breaker is supplied with rated insulating voltage 1150V and used for circuit of A.C. 50Hz, rated operating voltage AC 1140V. (or below), rated operating current up to 630A for infrequent changing over a...
Ver detalhes
NDM3-100 4P
